MT-HS-85A-LV-6V/5A/SBEC-V1

AUD$85.00



Maytech Harrier Supreme Series ESC , MT85A- LV -SBEC is a 85A, Switch mode 6V/5A Bec, brushless speed controller that can handle a maximum current burst of 100A. One of the highest  rated inbult Sbec ESC available on the market.

Its performance in terms of compatibility, reliability and stability can compete with world famous brands without the associated high price tag.

Features:

  • Support High RPM motors.
  • Circle menu setting is simple.
  • Power arming protection:
  • Prevents the motor from accidentally running when switched ON
  • Lost Throttle signal protection:
  • The ESC will automatically reduces output power to the motor when it detects a lost of throttle signal for 1 second. A subsequent loss of throttle signal beyond 3 seconds will cause the ESC automatically to cut power to the motor.
  • Safety thermal over-load protection:
  • Automatically reduce output power to half when the temperature reaches 110℃, restore output power when the temperature is below 110℃.
  • Motor  rotation direction can be easily set by programming card.
  • Reverisble motor direction using TS programming card.
  • Acceleration: Provides quick acceleration start ups with a linear throttle response.
  • Governor Mode: For Helicopter application
  • With latest humanize software design, especially for all types of brushless motor.
  • New advanced programming software.

Functions:

  • Brake Setting: on/off
    Note:Factory default setting: off.
  • Battery type: LiPo /NiMh/NiCad
    Note: Factory default setting: 3 Li- Poly
  • Under voltage protection (Low voltage cutoff type):

Reduce power:

  • Reduce motor speed to half throttle
  • Cut off: Stop motor immediately
  • Ignore: Motor won't stop until battery totally gone)
    Note: Factory default setting: Reduce power
  • Soft start (Acceleration): very soft/ soft/ start acceleration
    Note. Factory default setting: Soft start: Enable

Timing:

  • Automatic: (7-30 degree)
  • Soft: (7 -22 degree)
  • Hard :( 22-30 degree)
    Note. Factory default setting: Automatic
  • Frequency: 8 KHz/ 16 KHz, Factory default setting: 8 KHz
  • Heli Governor Mode: Factory default setting: rpm control off .
  • 100A Max Current Burst. With 6V/5A Switch Mode Bec.  (Ensure Servo's can handle 6V )
  • Input Voltage: 2-6sLipo or 5-18cells NiCD
    Net Weight : 46g


    The MAYTECH ESC's high power BEC has been specifically designed for extreme aerobatics and therefore has the capability to support the higher momentary peak demand loads to eliminate the possibility of unwanted shutdowns, and is also capable of supporting continuous simultaneous multiple servo operations typically found in CCPM equipped  E-helicopters. Maytech speed controllers can be programmed by transmitter or quickly and easily by using Maytech TS programming card.

Sold Out
  • Model: MT-HS-85A- LV -6/5SBEC
  • 0 Units in Stock
